BECO INTEGRA DISC MB-Range Stacked Disc Cartridge Housing
Images are representations only.

BECO INTEGRA DISC MB-Range Stacked Disc Cartridge Housing

Brand: Eaton Corporation
Request Information
Favorite

Eaton's BECO INTEGRA DISC MB stacked disc cartridge housing is an enclosed depth filtration system which can be used from coarse filtration to microbial removal filtration of liquids in the food and beverage industries.
Features
  • ATEX certified
  • High chemical resistance through the use of quality stainless steel materials, AISI 316 L / AISI 316 Ti
  • Easy handling and good cleanability thanks to ergonomic design
  • Quick and simple replacement of the empty stacked disc cartridges
  • Low capital costs with relatively large filter areas and simple integration into the process
  • Variable application options through the use of different stacked disc cartridges with flat or double O-ring adapter
  • Adaptation of the filter area to specific requirements through variable column heights
  • Small footprint through compact design and easy integration into the filtration process
  • Other designs and further components for expansion to complete systems are available, depending on requirements

Specifications

Brand

Filter Area

  • 20.45 to 159.31 ft² (1.9 to 14.8 m²)

Material of Construction

  • Contacting Part: Stainless Steel, AISI 316L
  • Other: Stainless Steel AISI 304

Surface

  • Ra < 0.8 µm

Certifications & Approvals

  • ATEX

Gasket/O-ring Material

  • Silicone
  • EPDM, Viton Available

Housing Closure

  • Clamp Screws
  • 12”: 5 Screws / 16”: 8 Screws

Filter Inlet/Outlet

  • DN 50, DIN 11851 (2")
  • Alternatives as TC or Flange

Vent Connection

  • TC 1.5" (ASME BPE)

  • Beer
  • Wine
  • Fruit Juice
  • Fruit Wine

Documentation

Data Sheets

Brochure
